Floor Spring S220

  • Floor Spring S220
Inquiry Prev Next
Product Description
SGS certified
Features:
  • Taiwan SGS certified
  • Suitable for single & double action doors.
  • Maximum door width 950mm, Maximum door opening 130°.
  • Available for hold open 90° , no hold open.
  • Speed adjustment valves can not be backed out of Floor Spring when adjustment , that eliminates oil leakage from the valves.
  • Adjustment valves of closing speed and latching speed are fully independent .
  • Two -piece cover plate , easy to adjust the center of the door and closing speed .
  • Screws on both sides to strengthen and increase the stability of the door after the installation .
Product Specification

TECHNICAL DATA

Closing force EN2 EN3
Door width(mm) 850 950
Door weight (kg) 60 80
Dimensions of cement case(mm) L297 x W145 x H48
Adjustment
in cement case(mm)		 L6 x W6
Dimensions cover plate(mm) L308 x W146 x H1
